Small High Torque 24BYJ48 Stepper Motor with 5.625°/64 Step Angle for Precision Control

500 pcs
MOQ
1~6 USD/PC
Price
Small High Torque 24BYJ48 Stepper Motor with 5.625°/64 Step Angle for Precision Control
Features Gallery Product Description Chat Now
Features
Specifications
Step Angle: （5.625°/64） /（11.25°/64）
Material: Copper Wire
Voltage: 12V / 5V DC
Diameter: 24mm
Resistance: 20~300Ω
Wire: 5
Application: Fan,Air Conditioner, Camera, Monitor, Air Conditioners, Intelligent Sanitary, Refrigerators, Automatic Door Lock Etc
Name: Small High Torque Stepper Motor 24BYJ48 For Air Conditioner Louver, Small Cooling Heating Fan And Automatic Curtains
OEM: Logo, Wire, Holes,parameters,gears Etc
Highlight:

Small Stepper Motor

,

High Torque 24BYJ48 Motor

,

5.625°/64 Step Angle Stepper Motor
Basic Infomation
Place of Origin: China
Brand Name: XM-Motor
Certification: ISO9001 ROHS
Model Number: 24BYJ48
Payment & Shipping Terms
Packaging Details: Carton
Delivery Time: 20 to 30 days after receiving deposit
Payment Terms: T/T
Supply Ability: 200,000 PCS/month
Product Description

Small High Torque Stepper Motor 24BYJ48 for air conditioner louver, small cooling heating fan and Automatic curtains



Product Introduction:

  • Model No: 24BYJ48
  • With same number of poles as the stator, the rotor is composed of permanent magnet material.
  • Features excellent dynamic performance and high output torque



24BYJ48 Stepper Motor Datasheets:

Model Voltage(V) Resistance(Ω) Step Angle (1-2P) /(2-2P) Frequency(PPS) Pull-in Torque(mN.m) Self-locating Torque(mN.m) No-loading pull-in frequency(PPS) No-loading pull-out frequency(PPS)
24BYJ48 5 20 (5.625°/64) /(11.25°/64) 100 ≥78.4 ≥34.3 ≥500 ≥900
12 50 (5.625°/64) /(11.25°/64) 500 ≥150 ≥49 ≥500 ≥900
12 70 (5.625°/64) /(11.25°/64) 500 ≥13 ≥49 ≥500 ≥900
12 200 (5.625°/64) /(11.25°/64) 400 ≥78.4 ≥34.3 ≥500 ≥900
12 70 (5.625°/16) /(11.25°/16) 400 ≥19.6 ≥19.6 ≥500 ≥900
12 70 (5.625°/32) /(11.25°/32) 400 ≥49 ≥19.6 ≥500 ≥900
12 50 (5.625°/37) /(11.25°/37) 500 ≥100 ≥34.3 ≥500 ≥900
24 200 (5.625°/64) /(11.25°/64) 400 ≥150 ≥34.3 ≥500 ≥900
24 300 (5.625°/64) /(11.25°/64) 400 ≥80 ≥34.3 ≥500 ≥900



Friendly Reminder:

The above 24BYJ48 series parameters are standard products, our company can do product design, development and production according to your special requirements. for more information, please email to bianwenhui@xingmaimotor.com



24BYJ48 DIMENSIONS: mm

Small High Torque 24BYJ48 Stepper Motor with 5.625°/64 Step Angle for Precision Control 0Small High Torque 24BYJ48 Stepper Motor with 5.625°/64 Step Angle for Precision Control 1Small High Torque 24BYJ48 Stepper Motor with 5.625°/64 Step Angle for Precision Control 2

Small High Torque 24BYJ48 Stepper Motor with 5.625°/64 Step Angle for Precision Control 3

24BYJ48 Stepper Motor Torque Curve:

Small High Torque 24BYJ48 Stepper Motor with 5.625°/64 Step Angle for Precision Control 4Small High Torque 24BYJ48 Stepper Motor with 5.625°/64 Step Angle for Precision Control 5Small High Torque 24BYJ48 Stepper Motor with 5.625°/64 Step Angle for Precision Control 6Small High Torque 24BYJ48 Stepper Motor with 5.625°/64 Step Angle for Precision Control 7

Small High Torque 24BYJ48 Stepper Motor with 5.625°/64 Step Angle for Precision Control 8



24BYJ48 Series Applications:


• Home appliances: Air conditioners, Electric fans, Projectors,Cameras, Monitors etc.



Small High Torque 24BYJ48 Stepper Motor with 5.625°/64 Step Angle for Precision Control 9

Small High Torque 24BYJ48 Stepper Motor with 5.625°/64 Step Angle for Precision Control 10

Workshop :



Small High Torque 24BYJ48 Stepper Motor with 5.625°/64 Step Angle for Precision Control 11

Custom BYJ Stepper Motors Tailored to Your Specific Needs



  • Logo printing :as your need.
  • Specific wiring or connector solutions: embedded wires or bare wires for select.customize the connector type according to your specifications, ensuring a perfect fit for your application.
  • Holes Customization: Can specify the direction, size, and quantity of the installation holes to match your design.
  • Parameters customization: Voltage,Resistance, Inductance, Number of Phases, Step Angle, Torque.
  • Gear customization: Dupont plastic gears, powder metallurgy gears or POM  clear powder gears for select.



Small High Torque Stepper Motor 24BYJ48 for air conditioner louver, small cooling heating fan and Automatic curtains
