10mm Miniature DC Gearmotor High Torque Micro Motor 5V VSM10-816G
| MOQ: | 10000PCS |
| Price: | 1~10 USD/PC |
| Standard Packaging: | CTN OR CUSTOMIZED |
| Delivery Period: | 35DAYS |
| Payment Method: | T/T,D/P,L/C |
| Supply Capacity: | 100000PCS/MONTH |
10mm Miniature DC Gearmotor
,5V DC Gear Motor High Torque
,High Torque Micro Motor 5V
| Type | Gear Motor | Torque | High Torque |
|---|---|---|---|
| Construction | Permanent Magnet | Continuous Current(a) | Customized |
| Certification | ROHS | Voltage(v) | 5V |
| Output Shaft | Customizable | Reduction Ratio | Customizable1:3~1000 |
| Directions | CW/CCW | Step Angle | 18 Degree |
| Highlight |
miniature dc gear motor,micro electric motor |
||
VSM10-816G 5V 10mm mini screw micro metal gearmotor high torque linear stepper motor
SM10-816G is the use of diameter 10MM micro stepper motor and 10*12 precision metal reduction gearbox combination, the reduction ratio can be customized according to customer needs.
Motor basic step angle is 18 degrees, that is, 20 steps per turn, plus the deceleration box deceleration effect, the final motor rotation angle resolution can reach 0.05~6 degrees, can be used in many requirements.
Precise control of the rotating position of the field.
1:5 1:3 1:20 1:10 1:380 1:30 1:50 1:63 1:150 1:298 1:500 and so on, the customer can according to different use torque speed requirements to match the speed ratio, at the same time.
Mechanical Dimension:MM
Given the proper driving frequency of the stepper motor can reach the determination of the speed and torque.
This product gear box uses the most advanced equipment in the international processing related parts, so the high precision, high efficiency, low noise, and the use of reasonable and reliable process, make the product has better reliability.
The power input part and standard stepper motor can be used as probe structure, FPC, FFC, PCB cable and other forms.
Part of the output of the motor can be used in a variety of output structure, such as the circular axis, D axis, and the wire rod!
Typical Applications
- Saliva Analyzer
- Blood Analyzer
- Welding Machine
- Intelligent Security Products
- Fiber Fusion Splicer
- Digital Electronics
Specifications
| PRODUCT NAME | 10mm geared stepper motor |
| MODEL | VSM10-816G |
| RESISTENCE | 39Ω±7% |
| OPERATING TEMPERATURE RANGE | -0~+55 ℃ |
| OEM & ODM SERVICE | AVAILABLE |
Product Detail Presentation
Torque Curve For Reference
Type of Wire Connect
Motor input method with Pin type,FPC, PCB, Lead wire etc.
These can be customized according to customer needs.
Shaft Type
Out shaft standard as follows,also can customerized due to the user drawings
welcome to contact customer service for more types
-
Round Type : DIA3mm. 4mm. 5mm
-
D-cut Type: DIA3-D2.5 DIA4-D3 etc
-
Screw Type: M3 M4 M5 Serial
-
Trape Type
-
I-cut Type: DIA3-I2 DIA4-I3
-
Other Type: Shaft with a hole etc
Type of Fixture Cover
The regular models are shown in the figure, and the special sizes can be customized.
