Mini Stepper Motor DC Fan Motor for Automatic Products with High Output Torque and Precision Control

5 pcs
MOQ
1~6 USD/PC
Price
Mini Stepper Motor DC Fan Motor for Automatic Products with High Output Torque and Precision Control
Features Gallery Product Description Chat Now
Features
Specifications
Step Angle: （5.625°/64） /（11.25°/64）
Material: Copper Wire
Voltage: 12V / 5V DC
Phase: 2~4
Resistance: 20~300Ω
Wire: 5
Application: Fan,Air Conditioner, Camera, Monitor, Air Conditioners, Intelligent Sanitary, Refrigerators, Automatic Door Lock Etc
Name: 20BYJ48 DC Fan Motor Mini Stepper Motor Stepping Motor For Automatic Products
OEM: Logo, Wire, Holes,parameters,gears Etc
Highlight:

Mini Stepper Motor

,

DC Fan Motor Stepper Motor

,

Automatic Products Stepper Motor
Basic Infomation
Place of Origin: China
Brand Name: XM-Motor
Certification: ISO9001 ROHS
Model Number: 24BYJ48
Payment & Shipping Terms
Packaging Details: Carton
Delivery Time: 20 to 30 days after receiving deposit
Payment Terms: T/T
Supply Ability: 200,000 PCS/month
Product Description

20BYJ48 DC Fan Motor Mini Stepper Motor Stepping Motor for automatic products



Product Introduction:

  • Model No: 24BYJ48
  • With same number of poles as the stator, the rotor is composed of permanent magnet material.
  • Features excellent dynamic performance and high output torque



24BYJ48 Stepper Motor Datasheets:

Model Voltage(V) Resistance(Ω) Step Angle (1-2P) /(2-2P) Frequency(PPS) Pull-in Torque(mN.m) Self-locating Torque(mN.m) No-loading pull-in frequency(PPS) No-loading pull-out frequency(PPS)
24BYJ48 5 20 (5.625°/64) /(11.25°/64) 100 ≥78.4 ≥34.3 ≥500 ≥900
12 50 (5.625°/64) /(11.25°/64) 500 ≥150 ≥49 ≥500 ≥900
12 70 (5.625°/64) /(11.25°/64) 500 ≥13 ≥49 ≥500 ≥900
12 200 (5.625°/64) /(11.25°/64) 400 ≥78.4 ≥34.3 ≥500 ≥900
12 70 (5.625°/16) /(11.25°/16) 400 ≥19.6 ≥19.6 ≥500 ≥900
12 70 (5.625°/32) /(11.25°/32) 400 ≥49 ≥19.6 ≥500 ≥900
12 50 (5.625°/37) /(11.25°/37) 500 ≥100 ≥34.3 ≥500 ≥900
24 200 (5.625°/64) /(11.25°/64) 400 ≥150 ≥34.3 ≥500 ≥900
24 300 (5.625°/64) /(11.25°/64) 400 ≥80 ≥34.3 ≥500 ≥900



Friendly Reminder:

The above 24BYJ48 series parameters are standard products, our company can do product design, development and production according to your special requirements. for more information, please email to bianwenhui@xingmaimotor.com



24BYJ48 DIMENSIONS: mm

Mini Stepper Motor DC Fan Motor for Automatic Products with High Output Torque and Precision Control 0Mini Stepper Motor DC Fan Motor for Automatic Products with High Output Torque and Precision Control 1Mini Stepper Motor DC Fan Motor for Automatic Products with High Output Torque and Precision Control 2

Mini Stepper Motor DC Fan Motor for Automatic Products with High Output Torque and Precision Control 3

24BYJ48 Stepper Motor Torque Curve:

Mini Stepper Motor DC Fan Motor for Automatic Products with High Output Torque and Precision Control 4Mini Stepper Motor DC Fan Motor for Automatic Products with High Output Torque and Precision Control 5Mini Stepper Motor DC Fan Motor for Automatic Products with High Output Torque and Precision Control 6Mini Stepper Motor DC Fan Motor for Automatic Products with High Output Torque and Precision Control 7Mini Stepper Motor DC Fan Motor for Automatic Products with High Output Torque and Precision Control 8

Mini Stepper Motor DC Fan Motor for Automatic Products with High Output Torque and Precision Control 9



24BYJ48 Series Applications:


• Home appliances: Air conditioners, Electric fans, Projectors,Cameras, Monitors etc.



Mini Stepper Motor DC Fan Motor for Automatic Products with High Output Torque and Precision Control 10Mini Stepper Motor DC Fan Motor for Automatic Products with High Output Torque and Precision Control 11

Mini Stepper Motor DC Fan Motor for Automatic Products with High Output Torque and Precision Control 12

Workshop :



Mini Stepper Motor DC Fan Motor for Automatic Products with High Output Torque and Precision Control 13

Custom BYJ Stepper Motors Tailored to Your Specific Needs



  • Logo printing :as your need.
  • Specific wiring or connector solutions: embedded wires or bare wires for select.customize the connector type according to your specifications, ensuring a perfect fit for your application.
  • Holes Customization: Can specify the direction, size, and quantity of the installation holes to match your design.
  • Parameters customization: Voltage,Resistance, Inductance, Number of Phases, Step Angle, Torque.
  • Gear customization: Dupont plastic gears, powder metallurgy gears or POM  clear powder gears for select.

20BYJ48 DC Fan Motor Mini Stepper Motor Stepping Motor for automatic products
