24BYJ48 Stepper Motor with Low Noise High Temperature Resistance and Precise Positioning for Air Purifiers

5 pcs
MOQ
1~6 USD/PC
Price
24BYJ48 Stepper Motor with Low Noise High Temperature Resistance and Precise Positioning for Air Purifiers
Features Gallery Product Description Chat Now
Features
Specifications
Step Angle: （5.625°/64） /（11.25°/64）
Material: Copper Wire
Voltage: 12V / 5V DC
Diameter: 24mm
Resistance: 20~300Ω
Wire: 5
Application: Fan,Air Conditioner, Camera, Monitor, Air Conditioners, Intelligent Sanitary, Refrigerators, Automatic Door Lock Etc
Name: 24BYJ48 Micro Reducer Stepping Motor For Air Purifier
OEM: Logo, Wire, Holes,parameters,gears Etc
Highlight:

Low Noise 24BYJ48 Stepper Motor

,

High Temperature Resistance Micro Reducer Stepping Motor

,

Precise Positioning Permanent Magnet Synchronous Motor
Basic Infomation
Place of Origin: China
Brand Name: XM-Motor
Certification: ISO9001 ROHS
Model Number: 24BYJ48
Payment & Shipping Terms
Packaging Details: Carton
Delivery Time: 20 to 30 days after receiving deposit
Payment Terms: T/T
Supply Ability: 200,000 PCS/month
Product Description

24BYJ48 Micro Reducer Stepping Motor For Air Purifier



BYJ stepper motor features:

1. High and low temperature resistance -40°C to 140°C. Lifespan over 10,000 hours.

2. Noise level as low as 40 dbs.

3. Anti-interference, unaffected by external factors and step loss.

4. Low-speed: 1 to 40 revolutions per minute.



24BYJ48 Stepper Motor Datasheets:

Model Voltage(V) Resistance(Ω) Step Angle (1-2P) /(2-2P) Frequency(PPS) Pull-in Torque(mN.m) Self-locating Torque(mN.m) No-loading pull-in frequency(PPS) No-loading pull-out frequency(PPS)
24BYJ48 5 20 (5.625°/64) /(11.25°/64) 100 ≥78.4 ≥34.3 ≥500 ≥900
12 50 (5.625°/64) /(11.25°/64) 500 ≥150 ≥49 ≥500 ≥900
12 70 (5.625°/64) /(11.25°/64) 500 ≥13 ≥49 ≥500 ≥900
12 200 (5.625°/64) /(11.25°/64) 400 ≥78.4 ≥34.3 ≥500 ≥900
12 70 (5.625°/16) /(11.25°/16) 400 ≥19.6 ≥19.6 ≥500 ≥900
12 70 (5.625°/32) /(11.25°/32) 400 ≥49 ≥19.6 ≥500 ≥900
12 50 (5.625°/37) /(11.25°/37) 500 ≥100 ≥34.3 ≥500 ≥900
24 200 (5.625°/64) /(11.25°/64) 400 ≥150 ≥34.3 ≥500 ≥900
24 300 (5.625°/64) /(11.25°/64) 400 ≥80 ≥34.3 ≥500 ≥900



Applications:

Stepper motors are widely used in security monitoring, office automation equipment, financial payment devices, stage lighting, smart home appliances, sanitary ware, textile machinery, robotics, and other automated monitoring applications requiring precise positioning, automatic aiming, and automatic recording.

Voltage, resistance, cable length, shaft length (flattened position), reduction ratio, and terminals are customizable.



24BYJ48 DIMENSIONS: mm

24BYJ48 Stepper Motor with Low Noise High Temperature Resistance and Precise Positioning for Air Purifiers 024BYJ48 Stepper Motor with Low Noise High Temperature Resistance and Precise Positioning for Air Purifiers 124BYJ48 Stepper Motor with Low Noise High Temperature Resistance and Precise Positioning for Air Purifiers 2

24BYJ48 Stepper Motor with Low Noise High Temperature Resistance and Precise Positioning for Air Purifiers 3

24BYJ48 Stepper Motor Torque Curve:

24BYJ48 Stepper Motor with Low Noise High Temperature Resistance and Precise Positioning for Air Purifiers 424BYJ48 Stepper Motor with Low Noise High Temperature Resistance and Precise Positioning for Air Purifiers 524BYJ48 Stepper Motor with Low Noise High Temperature Resistance and Precise Positioning for Air Purifiers 624BYJ48 Stepper Motor with Low Noise High Temperature Resistance and Precise Positioning for Air Purifiers 7

24BYJ48 Stepper Motor with Low Noise High Temperature Resistance and Precise Positioning for Air Purifiers 8



24BYJ48 Series Applications:



24BYJ48 Stepper Motor with Low Noise High Temperature Resistance and Precise Positioning for Air Purifiers 9

24BYJ48 Stepper Motor with Low Noise High Temperature Resistance and Precise Positioning for Air Purifiers 10

Workshop :



24BYJ48 Stepper Motor with Low Noise High Temperature Resistance and Precise Positioning for Air Purifiers 11

Custom BYJ Stepper Motors Tailored to Your Specific Needs



  • Logo printing :as your need.
  • Specific wiring or connector solutions: embedded wires or bare wires for select.customize the connector type according to your specifications, ensuring a perfect fit for your application.
  • Holes Customization: Can specify the direction, size, and quantity of the installation holes to match your design.
  • Parameters customization: Voltage,Resistance, Inductance, Number of Phases, Step Angle, Torque.
  • Gear customization: Dupont plastic gears, powder metallurgy gears or POM  clear powder gears for select.



24BYJ48 Micro Reducer Stepping Motor For Air Purifier
